SECTION II PIPER PA-18 PARTS CATALOG FIGURE 13
Fuselage Group Throttle, Cabin And Carburetor Heat Mixture Controls
Figure
No.
and Index Part Number Code Nomenclature Req. Serial Numbers Affected Price
Number
-28 12400-00 SWITCH ASSEMBLY – Ignition, with wires (shielded) 1 18-1 to 18-4308 inclusive NM!
14579-02 SWITCH ASSEMBLY – Ignition, with wires (shielded) 1 18-4309 to 18-8914 inclusive NM!
83952-02 SWITCH ASSEMBLY – Ignition, with wires (not shielded) 1 18-1 to 18-8914 inclusive NM!
-15302-002 SWITCH ASSEMBLY – Ignition, with wires (shielded) 1 18-8915 and up 565.04
15302-04 SWITCH ASSEMBLY – Ignition, with wires (not shielded) 1 18-8915 and up NM!
-29 487-774 SWITCH – Ignition 1 NM!
-30 -487-823 SWITCH – Ignition (#110-S-67) 2 17.66
-31 -15300-000 GUARD – Switch 2 40.17
-32 U15299-001 PANEL – Switch – Black 1 48.73
U15299-002 PANEL – Switch – Red 1 101.26
-33 U83161-002 HOSE – Airspeed, rubber (4 per ship, 135hp, 150hp) 2 5.91

When ordering, always specify part number, description, and serial number of aircraft

44
