Page 46 - Taylorcraft Interactive Digital Parts Catalog

PART NUMBER QUANTITY NOMENCLATURE PRICE
B-829-L 10 Nose Bulkhead Rib – Left NM!
B-829-R 10 Nose Bulkhead Rib – Right NM!
A-8043-L 2 Tip Rib – Left NM!
A-8043-R 2 Tip Rib – Right NM!
0923-2 L/R 2 Nose Tip Rib – State Left or Right NM!
B-880-1 2 Trailing Edge 268.46

A-A837 1 Aileron Control Link Assembly – Right Wing NM!
A-A839 1 Aileron Control Link Assembly – Left Wing NM!
Following are replacement parts for A-A837 and A-A339 assemblies
A-896 4 Inner Seat NM!
A-897 4 Outer Seat NM!
A-8062 1 Left Aileron Control Outer Sleeve NM!
A-8063 2 Aileron Control Inner Sleeve NM!
A-8068 1 Right Aileron Control Outer Sleeve NM!

Wing Struts and Trim

PART NUMBER QUANTITY NOMENCLATURE PRICE
B-A839-1 1 Left Jury Strut Complete NM!
Following are replacement parts for B-A839-1 assembly
B-A839-2 1 Rear Tube NM!
B-A839-3 1 Front Section NM!
B-7066 1 Airspeed Pitot Tube NM!

A-A817-1 1 Right Jury Strut Complete NM!
Following are replacement parts for A-A817-1 assembly
A-A817-2 1 Front Section NM!
A-A817-3 1 Rear Tube NM!

AN3-15A 8 Bolt 0.32
MS21044N3 8 Nut 0.24
UA-A819 4 Jury Strut Adjusting Screw 78.58
A-892 2 Clamp – Jury Strut to Front Lift Strut NM!
U2690-000 2 Clamp – Jury Strut to Front Lift Strut – Starting with model F19 serial number 39.35
F-137 and all front lift struts purchased from factory after 01/01/79.
U1296-000 2 Clamp – Jury Strut to Rear Lift Strut – For 2.360” struts only. 53.69
UA-A815 2 Front Lift Strut – We can now only supply new size larger front lift struts. They are 816.58
interchangeable with the previous front struts. 3.48 x 1.187. Strut cuffs, clamps and
tie down clamps must be replaced.

42
