SECTION II                            PIPER PA-18 PARTS CATALOG                                      FIGURE 9
         Fuselage Group                                                                      Covered Fuselage Assembly • Right View
            Figure
                                                                                        No.
          and Index  Part Number Code                  Nomenclature                    Req.    Serial Numbers Affected                    Price
           Number
          -61       408-813          WASHER – Control lock installation (#3535-10-02)    4    18-3771, 18-3781 to 18-8019                 NM!
                                                                                                inclusive
          -63       60723-02         PANEL ASSEMBLY – Fuselage, bottom, rear             1    18-7809041 and up                           NM!
          -64       60724-02         PANEL ASSEMBLY – Fuselage, bottom, center           1    18-7809041 and up                           NM!


         A –  Used on PA-18 airplanes 18-1 to 18-3770 inclusive and 18-3772 to 18-3785 inclusive and on PA-18A airplanes 18-1215 to 18-1969 inclusive.
         B –  Used when the fuel tank is installed in the right wing.
         C –  Used on PA-18 airplanes with serial numbers 18-1 to 18-4308 inclusive, 18-4311 to 18-4345 inclusive, and 18-4347 to 18-4361 inclusive.
         D –  Used on PA-18 airplanes with serial numbers 18-4309, 18-4310, 18-4346, 18-4362 and up.
         E –  Used on PA-18A airplanes with serial numbers 18-1215 and up.
         F –  Used on PA-18A airplanes with serial numbers 18-1262 to 18-2477 inclusive, 18-2480, 18-2481, 18-2484, 18-2485, 18-2489, 18-2490, 18-2492, 18-
            2497, 18-2498, 18-2506 and 18-2507.
         G –  Used on PA-18 95hp airplanes with fuel tank in left wing only.
         H –  Used on PA-18 airplanes with serial numbers 18-3771, 18-3781 and up if airplane incorporates metal belly panels.
         I –  Used on PA-18A airplanes with serial numbers 18-2478, 18-2479, 18-2482, 18-2483, 18-2486, 18-2487, 18-2488, 18-2491, 18-2493, 18-2494, 18-2495,
            18-2496, 18-2499 to 18-2505 inclusive and 18-2508 and up.
         J –  Providing your aircraft is not equipped with filler neck and cap, it will be necessary to order cap, part number 14102-00 when ordering these parts.
         K –  Used on PA-18A airplanes with serial numbers 18-1262 to 18-2492 inclusive, 18-2495, 18-2497, 18-2498, 18-2500, 18-2501, 18-2502, 18-2505 to 18-
            2508 inclusive.
         L –  Used on PA-18 airplanes with serial numbers 18-1 to 18-664 inclusive, and on all PA-18 airplanes with serial numbers 18-665 to 18-3013 inclusive when
            electrical equipment is not installed, and on all PA-18 95hp airplanes up to and including 18-3013.
         M – Used on PA-18A airplanes with serial numbers 18-2493, 18-2494, 18-2496, 18-2499, 18-2503, 18-2504, 18-2509 and up.









































                                  When ordering, always specify part number, description, and serial number of aircraft
