FIGURE 5
SECTION I PIPER PA-18 PARTS CATALOG Wing Panel Assembly, Uncovered
Wing Group (Showing Trailing Edge)
Figure
No.
Part
and Index Number Code Nomenclature Req. Serial Numbers Affected Price
Number
-65 U1202-00 C RIB ASSEMBLY – Tip, #13, LH, 95hp, 105hp, 125hp, 135hp 1 177.8
U1202-01 C RIB ASSEMBLY – Tip, #13, RH, 95hp, 105hp, 125hp, 135hp 1 178.74
U1202-00 E RIB ASSEMBLY – #16, tip, left, 135hp, 150hp 1 177.8
U1202-01 E RIB ASSEMBLY – #16, tip, right, 135hp, 150hp 1 178.74
-66 U1216-00 RIB – Nose, tip, LH 1 31.99
U1216-01 RIB – Nose, tip, RH 1 47.68
-67 U1200-02 RIB ASSEMBLY – Nose (10) right wing (8) left wing (16 per ship when 18 29.72
fuel tank installed in right wing) (20 per ship 135hp, 150hp, 18-
3771, 18-3781 and up)
-68 U1200-08 D RIB ASSEMBLY – Nose, special, #1 and #2, left wing (4 per ship when 2 32.52
fuel tank is installed in right wing)
-69 U1200-05 D RIB ASSEMBLY – Nose 1 41.8
U1200-05 E RIB ASSEMBLY – Nose wing, at lift strut fitting installation, 135hp, 2 41.8
150hp
-70 -14383-004 C SPAR ASSEMBLY – Front, LH, 95hp, 105hp, 125hp, 135hp 1 440.61
U14383-005 C SPAR ASSEMBLY – Front, RH, 95hp, 105hp, 125hp, 135hp 2 566.73
U14391-002 E SPAR ASSEMBLY – Front, LH, 135hp, 150hp 1 626.83
U14391-003 E SPAR ASSEMBLY – Front, RH, 135hp, 150hp 1 626.83
-71 U14453-004 D SPAR ASSEMBLY – Rear, 105hp, 125hp, 135hp, LH 1 506.04
U14453-005 D SPAR ASSEMBLY – Rear, 105hp, 125hp, 135hp, RH 1 506.04
U14392-002 E SPAR ASSEMBLY – Rear, LH, 135hp, 150hp 1 442.78
U14392-003 E SPAR ASSEMBLY – Rear, RH, 135hp, 150hp 1 442.78
-72 U13171-000 GUSSET – False spar installation (4 per ship model 95hp) 2 31.16
-73 U11151-002 PLATE – “U”, fair lead retainer 4 9.31
-74 U12331-002 E PLATE – Butt rib and leading edge attachment, 135hp, 150hp 2 5.58

A – Used when fuel tank is installed in right wing.
B – Used on airplanes with serial numbers 18-1 to 18-3770 inclusive, and 18-3772 to 18-3780 inclusive.
C – Used on PA-18 95hp airplanes with serial numbers 18-1 and up. Used on PA-18 and PA-18A 105hp, 125hp, 135hp airplanes with serial numbers 18-1 to
18-3770 inclusive, 18-3772 to 18-3780 inclusive.
D – Used on airplanes with serial numbers 18-1 to 18-3770 inclusive, and 18-3772 to 18-3780 inclusive.
E – Used on airplanes with serial numbers 18-3771, 18-3781 and up.

When ordering, always specify part number, description, and serial number of aircraft
