Page 28 - Aeronca 11AC Interactive Service Manual

2-808 PLATE TAB INDICATOR 7-519-4 INSTRUMENT PANEL TOP 7-519-1 INSTRUMENT PANEL BOTTOM 444244 OIL PRESSURE GAUGE C2400L4VF-35-50 COMPASS – AIRPATH AW2-3/4-32 ALTIMETER 4-599 COVER INST. TRIM 557 GV TACHOMETER AW2-3/4-16-B AIR SPEED IND. 442247 OIL TEMP. GAUGE ASSY. 1-2865 NAME PLATE 2-1029 WING ORNAMENT 1-2870 RETAINER ORNAMENT 2-840 ASH RECEIVER 3-605-1 GLOVE COMP. DOOR 3-522 GLOVE COMP. 4-716 L/R SEPARATOR 4-715 L/R WINDOW FRONT 3

4-705 BOARD SEAT BOTTOM 7-532 CUSHION BOTTOM 3-476 SAFETY BELT AN4-6 BOLT AN310-4 NUT

2-1013 FUEL SHUT OFF CONTROL

2-859 CABIN HEAT CONTROL 2-277-5 THROTTLE CONTROL 2-860 CARB. HEAT CONTROL 2-856 SWITCH ASSY. 1-788 PRIMER ASSY. 3-523 ENGINE CONTROL PANEL 4-594 WINDOW REAR 7-533 CUSHION BACK 3-604 RETAINER BOTTOM 7-528 BAGGAGE COMP. 3-509 BOARD BAGGAGE COMP. BOTTOM

1-2833 IDENTIFICATION TAG 3-605-2 GLOVE COMP. DOOR 1-2868 PLACARD AUX. FUEL

7-601-L/R FRONT PANEL 4-703-L/R REAR PANEL

1-2866 RING STARTER BOOT 3-615 BOOT – STARTER CRANK 3-521-L/R DECK LUGGAGE COMP. 3-508 LID LUGGAGE COMP. 1-192-3 PIN HINGE 1-192-2 HINGE 4-707 BOARD SEAT BACK 3-603 RETAINER TOP 3-504-L/R RETAINER FRONT

25
25
