Page 22 - Aeronca 11AC Interactive Service Manual
P. 22
1-1321 SPRING 2-1009 BRAKE PEDAL AN3-5A BOLT MS21044N3 NUT
AN3-13 BOLT AN310-4 NUT
AN3-4A BOLT MS21044N3 NUT
AN3-10 BOLT AN310-3 NUT 2-797 LEVER 1-2277 SECTOR 1-2519 SPRING 1-2325 LEVER
AN315-3 NUT 5626 EYEBOLT AN310-4 NUT AN315-3R NUT U1-2499 EYEBOLT
1-2453 BUSHING MS35206-246 TERMINAL MS21044N08 NUT #18 AIRCRAFT FERRULE 7-527-2 CABLE 1-2578-4 HOUSING AN4-4A BOLT MS21044N4 NUT 1-2817 LINK 1-2616 LINK 7-527-1 CABLE 1-2578-5 HOUSING U2-776-2 BRAKE CABLE U1-2578 HOUSING U2-776-2 BRAKE CABLE U1-2578 HOUSING AN3-6A BOLT MS21044N3 NUT
19
19
