Page 41 - Stinson 108 Series Interactive Digital Parts Catalog

STINSON DIVISION
UNIVAIR AIRCRAFT CORPORATION

FIGURE & NO.
ITEM NO. PART NUMBER PART NAME REQ’D MODEL PRICE
13-21 108-3001212 Pane – Cabin Window (SN 1 through 3499) 2 46-47-48 NM!
13-21 108-3002212 Pane – Cabin Window (SN 3500 and up) 2 48 NM!
13-22 108-6021405 Support – Firewall Engine Cowling 1 46-47-48 NM!
13-23 108-2311016 Strip – Vertical Stabilizer – Fabric Tie Down – Interior 1 46-47-48 23.8
13-24 108-3002282 Seal – Lower Forward Cabin Door 2 46-47-48 NM!
13-24 108-3002283 Seal – Door 20F 46-47-48 NM!
13-25 108-3091101-40 Snap-on – Cover – 26.75” Long 2 46-47-48 NM!
13-25 108-3091101-46 Snap-on – Cover – 31.00” Long 2 46-47-48 NM!
13-25 108-3092101-28 Snap-on – Cover – 24.00” Long 2 47-48 NM!
13-25 108-3092101-50 Snap-on – Cover – 10.50” Long 2 47-48 NM!
13-26 108-3091101-42 Retainer – Snap-on – Cover – 27.00” Long 2 46-47-48 NM!
13-26 108-3091101-44 Retainer – Snap-on – Cover – 30.75” Long 2 46-47-48 NM!
13-26 108-3092101-30 Retainer – Snap-on – Cover – 24.00” Long 2 47-48 NM!
13-26 108-3092101-52 Retainer – Snap-on – Cover – 10.50” Long 2 47-48 NM!
13-27 108-3091039-6 Stencil – Fin Insignia – LH 1 46-47-48 44.44
13-27 108-3091039-7 Stencil – Fin – Insignia – RH 1 46-47-48 44.44
13-28 108-3092112-6 Scuff Plate – Door Frame – LH 1 46-47-48 237.65
13-28 108-3092112-7 Scuff Plate – Door Frame – RH 1 46-47-48 237.65
13-29 108-2312020-6 Strip – Vertical Stabilizer – Fabric Tie Down – Interior – Side 2 48 13.76
13-30 108-2312020-8 Strip – Vertical Stabilizer – Fabric Tie Down – Interior – Leading Edge 1 48 13.47
13-31 108-3092129 Tray Assembly – Ash 2 48 76.14
13-32 33197-R Filler Strip – Rubber Moulding – Rear Window 134 48 39.95
33-33 108-3002240-0 Frame Assembly – Cabin Window – LH 1 48 NM!
13-33 108-3002240-1 Frame Assembly – Cabin Window – RH 1 48 NM!
13-34 34465-R Moulding – Rubber – Rear Window 2 48 103.19
13-35 108-3092145-6 Scoop – Cabin Ventilator – Rear – LH 1 48 114.89
13-35 108-3092145-7 Scoop – Cabin Ventilator – Rear – RH 1 48 114.89
13-36 108-3001213 Wood Strip, Top, Windshield 1 46-47-48 239.23
13-37 108-3001204-14 Strike Plate, Door Latch 2 46-47-48 18.27
13-38 1024 T-Nut 24 46-47-48 0.64

1 For airplanes serial 108-743 through 108-1989
2 For airplanes serial 108-1990 through 108-3500
3 For airplanes serial 108-2250 through 108-3500

35
