CAUTION: This map compartment should not be used when pulling the door closed.

Plexiglas is secured in the door and rear windows with Alumilastic compound and reinforced with
aluminum alloy channel. This method of installation insures a watertight seal. When installing new door
window, center the Plexiglas in the frame to allow for expansion front and rear. The Plexiglas should not
touch the frame at either the front or rear.

ENGINE CONTROL

A recessed panel located between front and rear seats left side of cabin houses ignition switch, carburetor
heater control and fuel shutoff valve. Safety-recessing these controls eliminates hazard of catching clothing
on them during flight.

FLOORBOARD SURFACES
Consist of three ply laminated fir, designed in three sections. Sections are finished with black DuLuxe
enamel and bolted to the fuselage floor frame.

18
