Page 22 - Stinson 108 Series Interactive Digital Parts Catalog

STINSON DIVISION
UNIVAIR AIRCRAFT CORPORATION

FIGURE & NO.
ITEM NO. PART NUMBER PART NAME REQ’D MODEL PRICE
MS21044N4 Nut (AN364 – 428) 4 48 0.3
7-30 108-3001445-0 Plate – Fuselage Horizontal Stabilizer Fairing – LH 1 46-47 52.3
7-30 108-3001445-1 Plate – Fuselage Horizontal Stabilizer Fairing – RH 1 46-47 52.3
7-31 108-2111005-6 Rib – Horizontal Stabilizer – Stations 28.00 and 27.50 Inboard Half 2 46-47 11.05
7-31 108-2111005-8 Rib – Horizontal Stabilizer – Stations 28.00 and 27.50 – Outboard Half 2 46-47 11.05
7-31 108-2111025 Rib – Horizontal Stabilizer – Station 28.00 2 48 84.24
7-32 108-2111006-6 Rib – Horizontal Stabilizer – Stations 35.00 and 34.62 – Inboard Half 2 46-47 25.45
7-32 108-2111006-8 Rib – Horizontal Stabilizer – Stations 35.00 and 34.62 – Outboard Half 2 46-47 25.45
7-32 108-2111026 Rib – Horizontal Stabilizer – Station 35.00 2 48 95.2
7-33 108-2111007-6 Rib – Horizontal Stabilizer – Stations 42.50 and 42.30 – Inboard Half 2 46-47 15.73
7-33 108-2111007-8 Rib – Horizontal Stabilizer – Stations 42.50 and 42.30 – Outboard Half 2 46-47 15.73
7-33 108-2111027 Rib – Horizontal Stabilizer – Station 42.50 2 48 87.39
7-34 108-2111008 Rib – Horizontal Stabilizer – Station 52.69 2 46-47-48 73.88
7-34A 108-2111001-6 Rib – Horizontal Stabilizer – Station 3.44 – LH – Inboard 1 46-47-48 133.38
7-34B 108-2111001-7 Rib – Horizontal Stabilizer – Station 3.44 – RH – Inboard 1 46-47-48 133.38
7-35 108-2111011 Fitting Assembly – Horizontal Stabilizer – Outboard Hinge (includes item 6) 2 46-47-48 182.66
7-36 108-2311013 Bracket – Vertical Stabilizer – Lower Hinge 2 46-47-48 11.83
7-37 108-2201012 Cover Assembly – Elevator Tab Mechanism 1 46-47-48 24.89
7-38 108-2611000-8 Skin – Rudder – Top – LH 1 46-47 39.01
7-38 108-2611000-9 Skin – Rudder – Top – RH 1 46-47 39.01
7-39 108-2311000-407 Tip Assembly – Vertical Stabilizer 1 46-47 61.84
7-40 108-2111000-34 Strip – Stabilizer Leading Edge 2 46-47 NM!
7-41 108-2312019-6 Band – Side – Fabric Trim – LH/RH 1 48 68.6
7-42 108-2312018-6 Band – Leading Edge – Fabric Trim 1 48 17.62
7-43 108-2111020-8 Skin – Horizontal Stabilizer – Inboard – LH 1 48 244.79
7-43 108-2111020-14 Skin – Horizontal Stabilizer – Inboard – RH 1 48 244.79
7-44 108-2111020-6 Skin – Horizontal Stabilizer – Outboard – LH 1 48 244.79
7-44 108-2111020-12 Skin – Horizontal Stabilizer – Outboard – RH 1 48 244.79
7-45 108-2611000-10 Spar – Rudder 1 46-47 155.76
7-46 108-2311000-10 Spar – Vertical Stabilizer 1 46-47 97.02
Note: Elevator Skins – The old style, 2 – piece skins are no longer available. The following 1 – piece skins
have “V” shaped corrugations and replace the original 2 – piece skin.
7-47 108-12908-B Skin – Elevator – LH – Upper 1 46-47-48 224.68
7-47 108-12908-B Skin – Elevator – LH – Lower 1 46-47-48 224.68
7-47 108-12908-B Skin – Elevator – RH – Upper 1 46-47-48 224.68
7-47 108-12908-B Skin – Elevator – RH – Lower 1 46-47-48 224.68
Note: Rudder Skins – The following “U Dimple” corrugated skins are no longer available. The following
skins have “V” shaped corrugations and replace the above skins.
7-48 108-2611000-6U Skin – Rudder – LH 1 46-47 295.33
7-48 108-2611000-7U Skin – Rudder – RH 1 46-47 295.33
7-49A 108-2611000-AL Angle – Fairing – Upper – LH 1 46-47 16.19
108-2611000-AR Angle – Fairing – Upper – RH 1 46-47 16.19
7-49B 108-2611000-B Angle – Fairing – Middle – LH or RH 2 46-47 16.19
7-49C 108-2611000-C Angle – Fairing – Lower – LH or RH 2 46-47 17.19
7-50 108-2311017 Band – Fabric Trim – Exterior 1 46-47 26.56
7-51 108-2312051 Bracket Assembly 1 48 115.88

16
