Page 21 - Stinson 108 Series Interactive Digital Parts Catalog

STINSON DIVISION
UNIVAIR AIRCRAFT CORPORATION

FIGURE & NO.
ITEM NO. PART NUMBER PART NAME REQ’D MODEL PRICE
MS21044N3 Nut (AN365-1032) 8 46-47 0.24
NAS1149F0363P Washer (AN960-10) 8 46-47 0.04
AN3-6A Bolt 4 46-47 0.16
MS21044N4 Nut (AN365-428) 4 46-47 0.3
NAS1149F0463P Washer (AN960-416) 4 46-47 0.06
7-11 108-2312050 1 Stabilizer Assembly – Vertical 1 48 NM!
7-12 108-2311014 Mast Assembly – Antenna 1 46-47 12.17
7-13 108-2311008 Spar – Vertical Stabilizer – Auxiliary 1 46-47 10.59
7-14 108-2311002-6 Rib – Vertical Stabilizer – Station 55.35 – LH Half 1 46-47 27.34
7-14 108-2311002-8 Rib – Vertical Stabilizer – Station 55.35 – RH Half 1 46-47 27.34
7-15 108-2311003-6 Rib – Vertical Stabilizer – Station 47.35 – LH Half 1 46-47 27.34
7-15 108-2311003-8 Rib – Vertical Stabilizer – Station 47.35 – RH Half 1 46-47 27.34
7-16 108-2311001 Rib – Vertical Stabilizer – Station 63.35 1 46-47 17.87
7-17 108-2311011 Bracket – Vertical Stabilizer – Upper Hinge 2 46-47 12.26
7-18 AN4-12A Bolt 5 46-47-48 0.36
MS21044N4 Nut (AN365-428) 5 46-47-48 0.3
108-8001001 Seal – Bearing 6 46-47-48 2.58
7-19 108-2111012 Fitting Assembly – Horizontal Stabilizer – Center Hinge (includes item 6) 1 46-47 182.66
7-20 108-2611012 Fitting – Vertical Stabilizer Hinge 1 46-47 181.07
7-21 108-2201007-0 Elevator Assembly – LH (includes item 26) 1 46-47-48 5440.59
7-21 108-2201007-1 Elevator Assembly – RH 1 46-47-48 5440.59
7-22 108-2201007-12 Skin – Tip – Elevator – Lower – LH 1 46-47-48 NM!
7-22 108-2201007-13 Skin – Tip – Elevator – Lower – RH 1 46-47-48 NM!
7-23 108-2201007-10 Skin – Tip – Elevator – Upper – LH 1 46-47-48 NM!
7-23 108-2201007-11 Skin – Tip – Elevator – Upper – RH 1 46-47-48 NM!
7-24 108-2201007-24 Rib – Tip – Elevator 2 46-47-48 135.25
7-25 108-2201007-22 Rib – Outboard – Elevator – LH 1 46-47-48 109.48
7-25 108-2201007-23 Rib – Outboard – Elevator – RH 1 46-47-48 124.77
7-26 108-2201001-0 Tab Assembly – Elevator Trim 1 46-47 360.8
7-26 108-2201001-0 Tab Assembly – Elevator Trim 1 48 360.8
7-27 108-2201006 Horn – Elevator 2 46-47-48 115.07
7-28 108-2201005 Stud – Tab Control Elevator Support 1 46-47-48 56.23
7-29 108-2111020 Stabilizer Assembly – Horizontal 1 46-47 8624.71
AN4-20A Bolt 2 46-47 0.4
MS21044N4 Nut (AN30-428) 2 46-47 0.3
NAS1149F0463P Washer (AN960-416) 2 46-47 0.06
AN24-8A Bolt 4 46-47 2.5
MS21044N4 Nut (AN364-428) 4 46-47 0.3
7-29 108-2111020 Stabilizer Assembly – Horizontal 1 48 8624.71
AN4-20A Bolt 2 48 0.4
MS21044N4 Nut (AN365-428) 2 48 0.3
NAS1149F0463P Washer (AN960-416) 6 48 0.06
AN24-14 Bolt 2 48 2.54
AN24-19A Bolt 2 48 1.68

1 Attaching parts same as 46-47
