Page 11 - Piper PA-16 Clipper Parts Catalog

PART NUMBER PER SHIP NOMENCLATURE PRICE
U11432-006 1 Weatherstrip – Sliding Window – Bottom 66.98
U11432-005 1 Weatherstrip – Sliding Window – Top 60.02
U11432-007 1 Weatherstrip – Sliding Window – Front 58.02
11432-008 1 Weatherstrip – Sliding Window – Rear NM!

-11631-000 1 Windshield 400.21
-11636-000 1 Window Assembly – Rear – Sliding 57.92
-11635-000 1 Window Assembly – Front – Sliding 57.92
-12011-000 1 Window – Enclosure – Rear – Right 48.26

INSTRUMENT PANEL GROUP
11906 Drawing – Instrument Panel Installation NM!
41481-07 1 Cable Assembly – Control – Cabin Heat NM!
41481-06 1 Cable Assembly – Control – Carburetor Heat NM!
41481-08 1 Cable Assembly – Control – Mixture NM!
41481-14 1 Cable Assembly – Control – Parking Brake NM!
W23X1A1G-5 1 Circuit Breaker – Lights – 5 Amp 43.12
W23X1A1G-15 1 Circuit Breaker – Radio – 15 Amp 39.96
W23X1A1G-15 1 Circuit Breaker – Generator – 15 Amp 39.96
11626-02 1 Control Assembly – Throttle NM!
471-048 1 Knob – Throttle Control NM!
12195-00 1 Door Assembly – Glove Compartment NM!
450-619 1 Instrument – Airspeed (PAC Drawing 10483-4) NM!
450-610 1 Instrument – Altimeter NM!
450-655 1 Instrument – Ammeter NM!
450-630 1 Instrument – Compass (PAC Drawing 10937) NM!
450-600 1 Instrument – Oil Temperature – Pressure Gauge NM!
450-675 1 Instrument – Safe Flight Indicator (includes wing unit and switch) NM!

450-641 1 Instrument – Tachometer (PAC Drawing 10485) NM!
-471-051 1 Knob – Glove Compartment Door 2.19
471-046 1 Knob – Navigation Light Switch NM!
CS11905-000 1 Panel Assembly – Instrument – Blank 55
12342-00 1 Panel Assembly – Instrument – Primary NM!
U1713-N340 1 Shaft – Tachometer With Core (non-recording) 166.15
750-907 1 Casing Assembly NM!
750-909 1 Core Assembly NM!
12325-00 1 Switch – Rheostat – Navigation Lights – with Wire less Knob NM!
493-130 1 Switch – Less Knob and Wires NM!

8
