415-14002-1 ERCOUPE LEADING EDGE SKIN

Applicability: Ercoupe 415 Series Highlighted part in illustration See charts below for aircraft applicability and related skins Leading edge skins are numbered from root to tip Crate fee CR16 will be included in the shipping costs at checkout. For...

415-16020-1-L ERCOUPE REINFORCEMENT - LEFT

Lower skin reinforcement, left hand

415-31110-L ERCOUPE UPPER LONGITUDINAL - LEFT

Frame "A" to "B" upper longitudinal, left Applicability: Ercoupe 415 series

415-31124-5 ERCOUPE FUSELAGE TANK PAD - BACK

Felt pad for fuselage tank, back Applicability: Ercoupe 415 Series, serial numbers 113 to 2623 Material: Felt Dimensions: 1.5 x 6 inches Highlighted parts in illustration 2 required per plane; priced and sold individually

415-33132 ERCOUPE TAPERED ATTACH WASHER

Main landing gear tapered attaching bolt washer Applicability: Ercoupe 415, serial numbers 113 to 812

415-33155 ERCOUPE KNEE JOINT STUD

Main landing gear knee joint stud Applicability: Ercoupe 415, serial numbers 113 to 812

415-33178 ERCOUPE SPACER

Wheel bearing spacer Effecitve on serial numbers 113 to 812

415-33210-R ERCOUPE FRONT FAIRING - RIGHT

Main landing gear fairing, right hand For serial numbers 813 and up

415-33447 ERCOUPE BRAKE RESERVOIR PLUG

415-34096-1 ERCOUPE AXLE SNAP RING

5.00 x 4 single bearing axle snap ring Applicability: Ercoupe 415, serial numbers 187 to 4500

415-34129 ERCOUPE SUPPORT

Oleo strut piston oil seal support Applicability: Ercoupe 415, serial numbers 187 to 4500 Highlighted part in illustration

415-34355-1 ERCOUPE SNAP RING

415-40038-L ERCOUPE UPPER LONGITUDINAL - LEFT

Engine cowl support upper longitudinal, left hand Highlighted part in illustration

415-40196 ERCOUPE TUBE

Front baffle strap tube

415-40198 ERCOUPE STRAP TUBE BAFFLE

Head baffle strap rear tube

415-40592-1 ERCOUPE SPINNER BACK PLATE

The following combination may be used on Ercoupe, Forney, Alon or Mooney with this bulkhead for the propeller and crankshaft combination shown. ConfigurationDomeFront Bulkhead Wood Propeller - Tapered Crankshaft F40593 N/A
