Product Description
- Applicability: Piper PA-22 150-160hp
- STC approved
The later model Tri-Pacers and Colts have a full gyro panel, identified by the raised portion on the left hand side. The production instrument panel was designed to accommodate the AN style instruments available at the time the airplanes were produced. Structural tubing behind the panel complicates the installation of deep instruments (such as a DG) low in the panel, hence the odd configurations seen in many airplanes.
This modification (STC SA00428SE) upgrades the panel to use modern 3-1/8" instruments. The panel has provisions for (7) 3-1/8" instruments and (1) 2.25" instrument. Form 337 required after installation. The installation of new 3-1/8" instruments is not a part of this STC and will require a separate Form 337.
Kit Includes:
| Description | Part Number | Quantity |
|---|---|---|
| Instrument Panel | 92WD005100-3 | 1 |
| Nut Plate | MS21059L06 | 6 |
| Rivet | MS20426A3-4 | 12 |
| Screw | MS24693S28 | 6 |
| Placard | 92WD005100-5 | 1 |
| Placard | 92WD005100-7 | 1 |
| Blueprints | - | 2 |
| STC Paperwork | - | 1 |
Product Videos
Custom Field
Aircraft Piper
