Scott 3200 Series and ABI-3200
The 3200 Series is a lightweight 8-inch tailwheel assembly designed to provide positive steering control far beyond rudder travel, and to release easily and automatically to full swivel when aircraft is turned around. The swivel mechanism is sealed to keep out water, sand and mud. Grease fittings are provided for lubrication. Precision components provide years of trouble-free service under severe operating conditions.
| No. | Description | Illustration |
|---|---|---|
| 1 | Bracket Assembly ABI-3216 |  |
| 2 | Bracket Assembly ABI-800613 | |
| 3 | Thrust Washer U3207 | |
| 4 | Thrust Plate Assembly U3234 | |
| 5 | Compression Spring U3233 | |
| 6 | Upper Dust Cap U3235A-002 | |
| 7 | Thrust Washer U3206 | |
| 8 | Arm Assembly U3214A-000 | |
| 9 | Pawl U3219A | |
| 10 | Lower Dust Cap U3235A-001 | |
| 11 | Fork Assembly ABI-3224 | |
| 12 | Cone Bearing A4050 | |
| 13 | Grease Retainer U1863A-000 | |
| 14 | Spacer U2504A-001 | |
| 15 | Washer NAS1149F0863P | |
| 16 | Shear Nut AN320-8 | |
| 17 | Cotter Pin MS24665-283 | |
| 18 | Spring U3222 | |
| 19 | Spacer U3258 | |
| 20 | Spacer U3258-1 | |
| 21 | Pin U3257 | |
| 22 | Axle Assembly U3236A-000 | |
| 23 | Lock Washer U3225A-000 | |
| 24 | Castle Nut AN310-8 | |
| 25 | Wheel Assembly ABI-3244-00 | |
| 26 | Tire and Wheel Assembly ABI-2600 | |
| 27 | Pin 3226 | |
| 28 | Gasket U2602 | |
| 29 | Bushing U3205A |
